Item Description:
Detecting range: 3cm-4M
Best in 30 degree angle
Electronic brick compatible interface
5VDC power supply
Breadboard friendly
Dual transducer
library ready
Specification:
Working Voltage: 5V (DC)
Static current: Less than 2mA.
Output signal: Electric frequency signal, high level 5V, low level 0V
Sensor angle: Not more than 15 degrees.
Detection distance: 2cm-450cm.
High precision: Up to 0.3cm
Working tempter:-20C___+60C
Weight: 10
Size: 45x 21mm (L x W)
Connector Pin:
VCC
Trig (T)
Echo(R)
OUT
GND
Package Included:
10 X HY-SRF05 Ultrasonic Ranging Sensor Module
